Toby & HSS Vol.2

bychan
Posted 17/04/2017 - 17:49 Link
Following the initial thread posted regarding using HSS to take photos of Toby, here's a selection from a "shoot" done a week later.

Same kit as before, different location, and no wind

1 ISO 320 f6.3 @ 1/320
Comment Image


2 ISO 250 f3.2 @ 1/1250
Comment Image


3 ISO 320 f6.3 @ 1/320
Comment Image


4 ISO 320 f6.3 @ 1/400
Comment Image


Regards
Adrian
K5IIs, Sigma 10-20, Pentax DA 16-85, Pentax DA 55-300, Pentax 70 Ltd, Metz 44 AF-2.
Flickr: https://www.flickr.com/photos/ambott/
McGregNi
Posted 17/04/2017 - 20:40 Link
Some nice low angles bring things down to your subjects level there, and the flash exposure looks good also ..... I'd have probably gone about a stop lower on the ambient background exposures here, they look a little bright, and you would get more depth and colour at about one stop less. Glad to see the HSS techniques are still proving useful!
My Guides to the Pentax Digital Camera Flash Lighting System : Download here from the PentaxForums Homepage Article .... link
Pentax K7 with BG-4 Grip / Samyang 14mm f2.8 ED AS IF UMC / DA18-55mm f3.5-5.6 AL WR / SMC A28mm f2.8 / D FA 28-105mm / SMC F35-70 f3.5-4.5 / SMC A50mm f1.7 / Tamron AF70-300mm f4-5.6 Di LD macro / SMC M75-150mm f4.0 / Tamron Adaptall (CT-135) 135mm f2.8 / Asahi Takumar-A 2X tele-converter / Pentax AF-540FGZ (I & II) Flashes / Cactus RF60/X Flashes & V6/V6II Transceiver
pschlute
Posted 17/04/2017 - 23:42 Link
Nice ones. Looking good Toby !!
stub
Posted 18/04/2017 - 09:37 Link
Great to see someone experimenting with HSS... Decent results too... Though I feel the -1 stop background tip is a good one,,, Well done...!!
K-1Gripped K-1 ungripped K-5ii K7 Various lenses

Stuart..
Stuey
Posted 18/04/2017 - 11:26 Link
Nice shots Adrian ☺️

Nice to see your model behaving well 😀
K10D, K5 plus plenty of clueless enthusiasm.

My Flickr site link
bychan
Posted 19/04/2017 - 00:48 Link
McGregNi wrote:
Some nice low angles bring things down to your subjects level there, and the flash exposure looks good also ..... I'd have probably gone about a stop lower on the ambient background exposures here, they look a little bright, and you would get more depth and colour at about one stop less. Glad to see the HSS techniques are still proving useful!
Yes experimenting with HSS has been good fun so far, with Toby being a great pro

Dumb question time now; when you suggest a stop lower for the ambient background, just drop the shutter by one stop?

Stu, long time no speak, hope you're well.

Thanks all.
K5IIs, Sigma 10-20, Pentax DA 16-85, Pentax DA 55-300, Pentax 70 Ltd, Metz 44 AF-2.
Flickr: https://www.flickr.com/photos/ambott/
pschlute
Posted 19/04/2017 - 01:47 Link
bychan wrote:


Dumb question time now; when you suggest a stop lower for the ambient background, just drop the shutter by one stop?

1 stop faster shutter speed will reduce the ambient background lighting without affecting your DOF. If you use a smaller aperture you will be affecting DOF which is critical for these kind of portrait shots although 1 stop shouldn't make much of a difference.

Question for Nigel......if one did use a smaller aperture to lower ambient light and increase DOF this would reduce the effective range of the fill flash, which is less anyway when using HSS, correct?
McGregNi
Posted 19/04/2017 - 19:11 Link
There's some interesting points raised about the control over the ambient and flash exposure balance here ....

Firstly, to answer Peter's question just above; yes, any smaller aperture setting will mean that more power is needed from the flash in order to maintain a fixed flash exposure level. With P-TTL flash this is automatically adjusted in response to your aperture changes, but a smaller aperture will reduce the effective range due to the higher power needed. This range is displayed on the flash info panel (eg. 1.5 - 8m, meaning between 1.5 and 8 meters the flash should be able to expose a subject correctly).

With normal, non-HSS, flash then the exposure time ('shutter speed') does not affect the flash exposure, however for HSS operation then then the shutter speed does affect flash exposure (just like aperture and ISO), and so each time you dial in a shorter exposure then the flash will be powering out more light to compensate (and again the effective range will drop, just as for the smaller aperture).

Assuming that the wide aperture is the 'priority' here (always nice for portraits), then the other settings to change to darken the background are the shutter and ISO ...... to take one example here, No.4 shot at ISO 320 f6.3 @ 1/400, then one-stop darker could be achieved by changing either the shutter speed to 1/800th, or reducing the ISO to 160 ...

Of course it is necessary to ensure that the other parameters stay fixed and don't move in response to your ISO or shutter adjustments, and the best way to ensure this is to work in Manual camera mode and make sure that auto-ISO is not active.
My Guides to the Pentax Digital Camera Flash Lighting System : Download here from the PentaxForums Homepage Article .... link
Pentax K7 with BG-4 Grip / Samyang 14mm f2.8 ED AS IF UMC / DA18-55mm f3.5-5.6 AL WR / SMC A28mm f2.8 / D FA 28-105mm / SMC F35-70 f3.5-4.5 / SMC A50mm f1.7 / Tamron AF70-300mm f4-5.6 Di LD macro / SMC M75-150mm f4.0 / Tamron Adaptall (CT-135) 135mm f2.8 / Asahi Takumar-A 2X tele-converter / Pentax AF-540FGZ (I & II) Flashes / Cactus RF60/X Flashes & V6/V6II Transceiver
Edited by McGregNi: 19/04/2017 - 19:13
pschlute
Posted 19/04/2017 - 19:46 Link
Thamks for the reply Nigel, I hadn't thought about shutter speed affecting the flash, but I understand now it will in HSS, thanks.
Stuey
Posted 19/04/2017 - 22:38 Link
[quote:Stu, long time no speak, hope you're well.[/quote]All ok thanks Adrian, I hope all is well with you 😀
K10D, K5 plus plenty of clueless enthusiasm.

My Flickr site link
derek897
Posted 19/04/2017 - 22:57 Link
Nice set, and a great example of flash put to great use.
I know what i like, If not always why.
bychan
Posted 21/04/2017 - 00:52 Link
Nigel and Peter, very well explained and greatly appreciated.

Thanks all.

K5IIs, Sigma 10-20, Pentax DA 16-85, Pentax DA 55-300, Pentax 70 Ltd, Metz 44 AF-2.
Flickr: https://www.flickr.com/photos/ambott/
