Wondering what the field of view of the DA lenses is on the K-1?


JAK

Link Posted 01/05/2016 - 12:42
A selection of blank images to show amount of vignetting at full aperture with DA lenses on the K-1

SMC Pentax-DA 14mm f2.8 ED(IF)



SMC Pentax-DA 15mm f4 ED AL Limited



SMC Pentax-DA 21mm f3.2 AL Limited



SMC Pentax-DA 35mm f2.8 Macro Limited



SMC Pentax-DA 50mm f1.8



SMC Pentax-DA 70mm f2.4 Limited



I'll add some others later
John K

bforbes

Link Posted 01/05/2016 - 12:47
Are these with the K1 in full frame mode or using the cropped sensor mode?
Barrie
Too Old To Die Young

http://www.pentaxphotogallery.com/artists/barrieforbes
https://www.flickr.com/photos/189482630@N03/

JAK

Link Posted 01/05/2016 - 12:51
Set to full frame.
John K

JAK

Link Posted 01/05/2016 - 13:07
For comparison a dedicated full frame lens:-

SMC Pentax-FA 50mm 1.4


John K

JAK

Link Posted 01/05/2016 - 13:38
SMC Pentax DA 55-300 ED@55mm




SMC Pentax DA 55-300 ED@98mm

SMC Pentax DA 55-300 ED@300mm



A real life photo at 300mm: SMC Pentax DA 55-300 ED@300mm f7.1


(Sorry about the weather!)

Again all at the full frame setting.
John K

JAK

Link Posted 01/05/2016 - 13:47
Another comparison - similar photo with the SMC Pentax-DA* 300mm f4@f7.1


John K

bforbes

Link Posted 01/05/2016 - 13:52
Your images seem to bear out RiceHigh's comparison chart. link
Barrie
Too Old To Die Young

http://www.pentaxphotogallery.com/artists/barrieforbes
https://www.flickr.com/photos/189482630@N03/

JAK

Link Posted 01/05/2016 - 14:23
An interesting one this: Samsung 10-17mm@14mm (Samsung's variant of the Pentax version.)
The field of view is quite useable from 14-17mm and comparable to using the lens on APSC, The walls on either side are at 90 degrees so FOV is wider than that. Zooming out to 10mm makes the image smaller (to fit the APCS-C sensor size) but content doesn't significantly change.


John K
Last Edited by JAK on 01/05/2016 - 14:34

JAK

Link Posted 01/05/2016 - 15:55
SMC PentaxDA 35mm f2.4@f2.4 (The budget plastic fantastic.)



At f2.4 - Some vignetting which is correctable if necessary, but it improves on stopping down.



By f8 vignetting is much less of an issue.


John K
Last Edited by JAK on 01/05/2016 - 16:13

Algernon

Link Posted 01/05/2016 - 16:05
The 10-17mm can be improved by shaving off the lens hood.

Shine a flashlight through the viewfinder to see how much needs to come off.
Alternatively remove it all or send it to Germany for a pro job.

http://www.indiavrtours.com/pic/tokina10-17mm.jpg

More info here.....

http://www.dpreview.com/forums/thread/3989620

There's also a youtube video...

https://www.youtube.com/watch?v=Z2e_X2p3IX4

--

--
Half Man... Half Pentax ... Half Cucumber

Pentax K-1 + K-5 and some other stuff

Algi

JAK

Link Posted 01/05/2016 - 16:12
SMC Pentax-DA 40mm f2.8 XS (The mini lens produced to pair with the K-01.)

At f2.8



At f2.8 - Not that much different from the 35mm plastic fantastic.



At f8 - hard to complain at that really - who would believe it!


John K

JAK

Link Posted 01/05/2016 - 17:04
SMC Pentax-DA 18-55mm AL WR

18mm f3.5



18mm f3.5



18mm f8



35mm f4.5



35mm f4.5



35mm f8



55mm f5.6



55mm f5.6



55mm f8 By this time image isn't too bad.



The sensor stains are simulated!
John K
Last Edited by JAK on 01/05/2016 - 17:06

JAK

Link Posted 01/05/2016 - 17:23
By comparison to an unshaved 10-17 this is the Sigma 8-16m HSM @14mm f7.1 (also unshaved!)
From 8 to 13mm the FOV is similar with edge blanked out like the Pentax/Samsung 10-17mm. I suppose shaving that might help too, or buy a Ricoh Theta.
Field of view achievable is slightly less than the 10-17 but is rectilinear.


John K
Last Edited by JAK on 01/05/2016 - 17:24

JAK

Link Posted 01/05/2016 - 17:43
SMC Pentax-DA 16-45mm ED-AL @19mm f6.3


19mm is the point the vignetting is almost eliminated. Vignetting significantly worse at wider focal lengths but from 20-45mm is unnoticeable and lens quite usable.
John K

JohnX

Link Posted 01/05/2016 - 18:21
I'm finding this thread of yours very interesting, thanks John, not least because I'm torn between buying the K1 or waiting to see when (if?) Pentax produce another APSC body, as I have an indecent number of perfectly good DA and DA* lenses, but take the view that buying the K1 would be a waste of money as it really needs FAs.

Or does it?

Will you be posting photos made with DA lenses in K1 crop mode?
Last Edited by JohnX on 01/05/2016 - 18:22
